Description

D35 R134a Refrigerator Compressor

The BD35 R134a Refrigerator Compressor (Model BD35F) is a high-performance, energy-efficient reciprocating compressor designed for mobile and stationary refrigeration systems. Manufactured with advanced engineering and robust materials, the BD35F is widely used in marine refrigeration, caravans, RVs, solar-powered fridges, medical refrigeration units, and portable cooling systems. Known for its compact size, low power consumption, and reliability, this compressor is an industry standard for small to medium cooling applications.

Powered by direct current (DC 12–24V) and capable of operating with a universal electronic control module, the BD35F offers excellent flexibility for a variety of refrigeration environments. Its design is optimized for HBP (High Back Pressure), MBP (Medium Back Pressure), and LBP (Low Back Pressure) applications, ensuring stable performance across a wide cooling range.

The compressor uses R134a refrigerant, making it environmentally friendly and compliant with global standards. Built with a durable black finish and EU small base plate type, the BD35F is compact yet powerful, allowing easy integration into small refrigerator systems without compromising on cooling performance.

Technical Highlights:

• Model: BD35F

• Type: Reciprocating Compressor

• Application Energy Level: Direct current

• Voltage Range: 12V – 24V DC (Min 9V / Max 31V)

• Refrigerant: R134a (Max charge 0.3 kg)

• Capacity Control: Fixed speed

• Swept Volume: 2 cm³

• Free Gas Volume: 870 cm³

• Compressor Motor Type: DC/PM

• Oil Type & Quantity: POE, 150 cm³

• Height from Baseplate: 91 mm (total height 96 mm)

• Dimensions: Length 178 mm, Width 100 mm

• Connections:

  • Suction – 6.5 mm, 40° angle, Cu-plated steel

  • Discharge – 5 mm, 21° angle, Cu-plated steel

  • Process – 6.5 mm, 45° angle, Cu-plated steel

• Operating Segments: LT (Low Temp), MT (Medium Temp), HT (High Temp)

• Winding Temperature: Up to 135°C short-term

Key Benefits:

• Compact & Lightweight – Easy to integrate into confined spaces.

• Dual Voltage (12/24V) – Compatible with multiple refrigeration setups.

• Energy Efficient – Low power draw for extended battery and solar applications.

• Durable & Reliable – Built for harsh environments like marine and off-grid use.

• Versatile Application – Suitable for marine fridges, truck fridges, RVs, solar refrigerators, and more.

At Climax Marine, we provide genuine and reliable marine refrigeration compressors and spare parts to ensure your cooling systems run efficiently. The BD35 R134a compressor is the trusted choice for professional marine engineers, yacht owners, and refrigeration technicians worldwide.

Upgrade your cooling system today with the BD35 R134a Refrigerator Compressor (BD35F) – engineered for durability, efficiency, and consistent performance in demanding environments.
